China High Performance Pneumatic Three-piece Clamp Ball Valve

This high-performance pneumatic clamp three-piece ball valve, is designed for precise flow control in various working conditions. This innovative valve features advanced design and manufacturing technology, ensuring exceptional sealing performance and low operating torque. The clamp connection simplifies installation and reduces maintenance costs, while the pneumatic actuator design allows for remote control and automated operation. Ideal for systems requiring frequent adjustments and quick response, this valve offers reliable performance and ease of use. With its high-quality construction, this valve is an excellent choice for a wide range of industrial applications.

     High Performance Pneumatic Three-piece  Clamp Ball Valve

     High Performance Pneumatic Three-piece  Clamp Ball Valve

    The high-performance pneumatic clamp three-piece ball valve adopts advanced design and manufacturing technology to ensure accurate flow control under various working conditions. The valve adopts a three-piece structure, providing excellent sealing performance and low operating torque. The clamp connection method simplifies the installation process, allowing the valve to be loaded and unloaded in a short time, reducing maintenance costs. The design of the pneumatic actuator allows remote control and automated operation, suitable for systems that require frequent adjustments and fast response.



    Technical parameters:

    1. Nominal diameter: DN15 - DN200 (or customizable as required ).

    2. Working pressure: 1.6Mpa to 6.4Mpa, based on the different diameter and temperature.

    3. Working temperature: -20℃ to +232℃, depending on the selected material and seal combination.

    4. Flow control: accurate, can be adjusted in small amounts.

    5. Applicable media: water, gas, oil, chemicals, etc.

    6. Control signal: standard 4-20MA current signal or air pressure signal.

    7. Control mode: switch type, regulating type or proportional type.

    8. Interface mode: different electrical or pneumatic accessories can be selected to adapt to different control systems.



    Material specifications:

    1. Valve body material: stainless steel, carbon steel or other alloy materials to adapt to different working environments.

    2. Ball material: stainless steel, carbon steel or other alloy materials, the surface may be specially treated to improve corrosion resistance.

    3. Sealing material: ptfe, ppr, metal seal, etc. to ensure sealing performance under different pressures and temperatures.

    4. Pneumatic actuator material: aluminum alloy, stainless steel or cast iron, selected according to valve size and operating frequency.

    5. Clamp material: stainless steel or galvanized steel to ensure the firmness and corrosion resistance of the connection.

    The above technical parameters and material specifications are only for general reference. The high-performance pneumatic clamp three-piece ball valve in actual application should be selected and customized according to specific working conditions and user requirements. Before purchasing, you should communicate with the manufacturer or supplier in detail to obtain the product specifications and performance indicators that best meet your needs.
